Integrated three-band frequency isolator allows you to customise the frequency spectrum of your master output for unique and creative transitions
Kill cut feature allows you to completely remove low, mid, or high frequencies, great for buildups
Resonant multimode filter offers low-pass, high-pass or bandpass options
Four stereo input channels with gain control, clip indication, and three-band EQ
Input channels provide two stereo inputs each
One timecode output per channel for connecting to Digital Vinyl Systems to make hybrid mixes
Inputs switchable between phono and line, adding further connectivity
Two microphone input channels with gain control, two-band EQ, and on-air switch
16-digit LED level meter lets you monitor booth or master outputs
Booth output with separate two-band EQ and level control for further mix customisation
Pre-fader listening with separate level meter, level control, PFL/master mix control
Cue mix/split ensures you can monitor every element of your mix with complete confidence and avoid clipping
Assignable VCA crossfader with adjustable curve for tactile fading
Two effects send and return chains for integrating external processing
Supplied mounting brackets provide optional rack installation
Specifications
Power Supply: 100 - 240 V AC, 50/60 Hz
Power Consumption: 24 W
Protection Class: Class I
Power Connection: Mains input IEC connector (M) mounting version power supply cord with safety plug (provided)
Frequency Response:
Microphone: 20 Hz - 20 kHz
Line: 20 Hz - 20 kHz
Phono: 40 Hz - 18 kHz
Signal-to-Noise Ratio:
Line: > 97.2 dB
Microphone: > 91.7 dB
THD:
Line: < 0.04% at 1 kHz
Phono: < 0.13% at 1 kHz
Microphone: < 0.008% at 1 kHz
Gain:
Microphone: 44 dB
Line: -16.5 dB to +8.5 dB
Phono: -48.5 dB to +23.5 dB
Isolators:
Master Gain: -∞ dB to +9 dB
Low-Mid: 300 Hz, 18 dB/octave, Butterworth
Mid-High: 4000 Hz, 18 dB/octave, Butterworth
Crosstalk: >-68 dB
Control Elements: Power switch, source selector, Crossfader, Crossfader selector switch, Crossfade curve switch; Cue mix split function, EQ controls
Status LED: Power, master level meter, clip, CUE
Connections:
Input: Line via 4 x stereo RCA
Input: Line/phono via 4 x stereo RCA
Input: Microphone via 2 x 3-pin XLR
Output: Headphones via 1 x 6.3 mm jack socket (stereo) mounting version
Output: Headphones via 1 x 3.5 mm jack (stereo) mounting version
Output: Record via 1 x stereo RCA
Output: Booth via 2 x 3-pin XLR
Output: Booth via 1 x stereo RCA
Output: Master via 2 x 3-pin XLR
Output: Master via 1 x stereo RCA
Output: AUX sends via 1 x 6.3 mm jack socket (stereo) mounting version
Output: AUX returns via 1 x 6.3 mm jack socket (stereo) mounting version
Output: Timecode via 4 x stereo RCA
Channels:
Input Channel: 4 x stereo with Line-Line/Phono switch via RCA, channel control via Rotary, 3-band tone control EQ, source selector, gain control, CUE switch, FX routing switch, Crossfader selector switch
Microphone Channel: 2 x mono via XLR, channel control via Rotary dial, ON AIR switch
Master Output: 2 x stereo via XLR, channel control via Rotary
Booth Output: 2 x stereo via XLR, channel control via Rotary
Record Output: 1 x stereo via RCA
Headphones Output: 1 x stereo via Plug 6,3mm/3,5mm (Jack), channel control via Rotary dial, Cue mix split function
