From musicians to sound engineers, there’s one thing every professional needs - reliability. That’s why the AZX-118A utilises Class-D amplification. Built for efficient performance, you get the same outstanding bass response without the added bulk. No heat sinks. No heavy components. Just great sound. Connect with ease thanks to a built-in crossover network. The AZX-118A takes the hassle out of frequency management. That means no stray frequencies getting in the way of your show. You can focus less on your gear, and more on your performance.
Features
Deep bass, all the way down to 40Hz
Articulate low-end reproduction from an 18” woofer
Fast transients from a 76mm voice coil
Reliable and efficient class D amplification technology
Massive power with 400W RMS onboard
Reduces unwanted resonance with a bass-reflex enclosure
Easy to connect with via XLR in, Parallel out L/R, and XLR out L/R with high-pass filter
Manage frequencies with ease thanks to an adjustable crossover
Correct phase alignment with the reversal switch
Protected against overload thanks to a built in limiter
Monitor performance with the limit, signal, and power LED
Transport with ease thanks to built-in carry handles
Robust MDF construction for an extended lifespan
Scratch and scuff resistant lacquer surface
Resistant against impact with a steel grille
Specifications
Power supply: 230 V AC, 50 Hz
Power consumption: 650 W
Power connection: Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
Rated power: 400W RMS
Frequency range: 40 – 250Hz
Sensitivity: 95 dB (1W/1m)
Crossover frequency: 80 – 200Hz
Attachment system: M20 thread
Circuitry: Class D
Connections: Input: 2 x line via 3-pin XLR, Output: 2 x line via 3-pin XLR, Output: 2 x high-pass via 3-pin XLR
